45° Stainless Steel Rigid Elbows - Type 316
Our 45° Rigid Elbows (Type 316) offer reliable, corrosion-resistant solutions for redirecting rigid conduit in electrical installations. Designed for industries that demand high sanitary standards and durability, these elbows are crafted from premium 316L stainless steel, making them ideal for environments exposed to moisture, chemicals, and other corrosive elements. The 45° bend is perfect for applications requiring angular changes, allowing for flexibility in conduit layout without compromising structural integrity.
Key Features:
- High-Quality Stainless Steel: Made from type 316L stainless steel for exceptional corrosion resistance, especially in challenging and hygienic environments.
- Brite Polished Finish: The “brite” polished finish not only enhances corrosion resistance but also provides a clean, professional appearance suitable for visible installations.
- Thread Protection: Comes with color-coded plastic caps to protect threads, ensuring easy identification and preserving thread integrity during storage and handling.
- Industry Compliance: Certified to meet various standards, including CULUS 6A, NEC, NSF/ANSI, and PROP65, for safety and performance assurance.
Specifications:
- Material: 316L Stainless Steel
- Available Angles: 90° and 45°
- Standards & Certifications:
- CULUS 6A (File Number: E230584)
- NEC Compliant
- NSF/ANSI Certified
- PROP65 Warning: Use caution and ventilation when cutting or performing hot work, as this may cause cancer. For more information, visit
Our 45° Stainless Steel Rigid Elbows are designed to meet the rigorous demands of industries such as food processing, pharmaceuticals, and outdoor environments, where sanitation and corrosion resistance are critical. Choose these stainless steel elbows for dependable, long-lasting performance in your conduit installations. Available from trusted brand Calbrite.
| Catalog Number | Trade Size | Outside Diameter (in) | Wall Thickness (in) | Angle (°) | Bend Radius (in) | Part Weight (lb/ea) | Standard Package Qty (ea) | Standard Package Weight (lb) |
|---|---|---|---|---|---|---|---|---|
| S60545EL00 | 1/2 | 0.840 | 0.110 | 45 | 4.0 | 0.63 | 1 | 0.63 |
| S60745EL00 | 3/4 | 1.050 | 0.115 | 45 | 4.5 | 0.89 | 1 | 0.89 |
| S61045EL00 | 1 | 1.315 | 0.132 | 45 | 5.8 | 1.21 | 1 | 1.21 |
| S61245EL00 | 1-1/4 | 1.660 | 0.140 | 45 | 7.3 | 2.25 | 1 | 2.25 |
| S61545EL00 | 1-1/2 | 1.900 | 0.145 | 45 | 8.3 | 3.25 | 1 | 3.25 |
| S62045EL00 | 2 | 2.375 | 0.153 | 45 | 9.5 | 5.05 | 1 | 5.05 |
| S62545EL00 | 2-1/2 | 2.875 | 0.202 | 45 | 10.5 | 9.50 | 1 | 9.5 |
| S63045EL00 | 3 | 3.500 | 0.215 | 45 | 13.0 | 13.36 | 1 | 13.36 |
| S64045EL00 | 4 | 4.500 | 0.235 | 45 | 16.0 | 19.80 | 1 | 19.8 |
