Micro Duct Packs | Gulfstream 350+ & 400 | Mini-Blower/Pusher
$804.50
Unit price
/
Select Option
Each
Micro Duct Packs | Gulfstream 350+ & 400 | Mini-Blower/Pusher — Product Overview
Micro Duct Packs are compatible with Condux Gulfstream 350+, Gulfstream 400 and Mini-Blower/Pusher systems. Available configurations accommodate duct outside diameters of 10, 12, 12.7, 14, 16 and 18 mm.
Select the appropriate duct pack by matching your duct outside diameter to the part number in the ordering table. Corresponding duct clamp, duct seal and end stop connector part numbers are included in the table for component identification.
Key Features
- Machine Compatibility – For Gulfstream 350+, Gulfstream 400 and Mini-Blower/Pusher systems.
- Six Duct Sizes – Available for 10, 12, 12.7, 14, 16 and 18 mm duct outside diameters.
- Size-Specific Selection – Individual duct pack part numbers identify each available size.
- Component Cross-References – The ordering table identifies matching duct clamps, duct seals and end stop connectors.
Ordering Information
| Duct Size OD (mm) | Duct Pack Part Number | Duct Clamp | Duct Seal | End Stop Connector |
|---|---|---|---|---|
| 10 | 08764140 | 08764142 | 08764143 | 08566325 |
| 12 | 08764110 | 08764112 | 08764113 | 08566327 |
| 12.7 | 08764150 | 08764151 | 08764153 | 08566338 |
| 14 | 08764120 | 08764122 | 08764123 | 08566328 |
| 16 | 08764130 | 08764132 | 08764133 | 08566329 |
| 18 | 08781110 | 08781106 | 08781101 | 08566334 |
Selection note: Duct size refers to outside diameter (OD). Match your duct size and equipment model before ordering. Component part numbers are provided for reference and do not represent additional selectable variants in this listing.
