Series 415 Side Fusion Tapping Saddle | 3" Base | DIPS
Series 415 Side Fusion Tapping Saddle | 3" Base | DIPS ā Product Overview
The Poly-Cam Series 415 Side Fusion Tapping Saddle provides a heavy-duty, low-profile solution for connecting to HDPE mains. Its barbed mechanical design is hydraulically compressed into polyethylene or pipe-grade copolymer, ensuring a high-strength, leak-resistant bond. A stainless steel compression ring adds exceptional pullout resistance, while the female-threaded outlet allows secure connection of valves or corporation stops.
Designed for sidewall fusion with standard fusion equipment, the 3" base is field-machinable to match DIPS mains ranging from 2" to 63" in diameter. This ensures a custom fit and dependable performance at the jobsite, even under fluctuating pressures and temperatures.
With a 335 PSI pressure rating and a minimum 50-year design life at 73.4Ā°F (23Ā°C) with a 2:1 safety factor, this tapping saddle is built for reliability in both utility and industrial HDPE systems.
Key Features & Benefits
- Threaded Branch Outlet: Female NPT or CC (AWWA) threads from 0.5" to 2"
- 3" Pivot Base Design: Field-machinable to fit DIPS mains from 2" to 63"
- Mechanical Barbed Seal: Hydraulically compressed design for long-term integrity
- Stainless Compression Ring: Maximizes pullout strength and reliability
- High Pressure Rating: Rated for 335 PSI
- Material Options: C954 Aluminum Bronze (lead-free), 304 SS, 316 SS, and PE 4710 HDPE
- Threading Compliance: ANSI/ASME B1.20.1ā2013
- Certified Construction: Meets ASTM D1598, D1599, AWWA C906, NSF 61 (PM13569), ARRA compliant
- Made in the USA
Common Applications
- Municipal Water Systems
- HDPE Tapping and Service Connections
- Industrial Fluid Distribution
- Sidewall Fusion Projects
- Utility and Infrastructure Valve Installations
Available Configurations (3" BASE DIPS)
š View All Series 415 Transition Fittings
| Base Size | Main Size (IN) | Outlet Size & Thread |
|---|---|---|
| 3" BASE | 2" | 0.5" NPT |
| 3" | 0.5" NPT | |
| 4" | 0.5" NPT | |
| 6" | 0.5" NPT | |
| 8" | 0.5" NPT | |
| 10" | 0.5" NPT | |
| 12" | 0.5" NPT | |
| 3" BASE | 2" | 0.75" NPT |
| 3" | 0.75" NPT | |
| 4" | 0.75" NPT | |
| 6" | 0.75" NPT | |
| 8" | 0.75" NPT | |
| 10" | 0.75" NPT | |
| 12" | 0.75" NPT | |
| 3" BASE | 2" | 0.75" CC |
| 3" | 0.75" CC | |
| 4" | 0.75" CC | |
| 6" | 0.75" CC | |
| 8" | 0.75" CC | |
| 10" | 0.75" CC | |
| 12" | 0.75" CC | |
| 3" BASE | 2" | 1" NPT |
| 3" | 1" NPT | |
| 4" | 1" NPT | |
| 6" | 1" NPT | |
| 8" | 1" NPT | |
| 10" | 1" NPT | |
| 12" | 1" NPT | |
| 3" BASE | 2" | 1" CC |
| 3" | 1" CC | |
| 4" | 1" CC | |
| 6" | 1" CC | |
| 8" | 1" CC | |
| 10" | 1" CC | |
| 12" | 1" CC | |
| 3" BASE | 2" | 1.25" NPT |
| 3" | 1.25" NPT | |
| 4" | 1.25" NPT | |
| 6" | 1.25" NPT | |
| 8" | 1.25" NPT | |
| 10" | 1.25" NPT | |
| 12" | 1.25" NPT | |
| 3" BASE | 2" | 1.25" CC |
| 3" | 1.25" CC | |
| 4" | 1.25" CC | |
| 6" | 1.25" CC | |
| 8" | 1.25" CC | |
| 10" | 1.25" CC | |
| 12" | 1.25" CC | |
| 3" BASE | 2" | 1.5" NPT |
| 3" | 1.5" NPT | |
| 4" | 1.5" NPT | |
| 6" | 1.5" NPT | |
| 8" | 1.5" NPT | |
| 10" | 1.5" NPT | |
| 12" | 1.5" NPT |
