710 Series HDPE Transition Fitting | Male NPT Thread | DR 7 IPS
710 Series HDPE Transition Fitting | Male NPT Thread | DR 7 IPS — Product Overview
Poly-Cam Series 710 Male NPT Thread Transition Fittings provide secure, long-lasting connections between HDPE conduit and NPT-threaded components. This durable transition uses a multi-level barb system that mechanically compresses HDPE or copolymer pipe into the metal fitting for a reliable seal.
The fittings are designed for use with IPS DR 7 conduit and are available in sizes from 0.5" to 12" NPT thread. Manufactured using high-quality materials such as C954 Aluminum Bronze, 304 Stainless Steel, 316 Stainless Steel, and Carbon Steel, these fittings are suitable for a variety of high-pressure and industrial-grade systems.
All transitions can be made AIS (American Iron and Steel) or BABA compliant upon request.
✅ Key Features & Benefits
- Leak-Proof Fusion Seal – Multi-level barb system permanently compresses HDPE (or CTS* diameter)
- Multiple Material Options – Choose from Carbon Steel, 304 SS, 316 SS, or PVC
- Standard NPT Thread Sizes – Compliant with ANSI/ASME B1.20.1 – 2013 standards
- Pressure Rated DR 7 – Ideal for high-pressure conduit systems
- Copoly-Ready Design – HDPE and copolymer compatible
- Low-Profile Configuration – Allows male pipe insertion without extended arm fittings
- BABA/AIS Available – Upon request
📐 Technical Specifications
- Series: 710
- Outlet Thread Size: 0.5"–12" Male NPT
- Available DR Rating: DR 7 IPS
- Main Size Compatibility: 0.5" to 12" HDPE conduit
- Fusion Type: Multi-level barb compressed design
- Installation Method: Hydraulic fusion per Plastic Pipe Institute guidelines
- Materials: C954 Aluminum Bronze, 304 SS, 316 SS, Carbon Steel
- Standards: ASTM 1598, 1599, D3261, F714, D3350, AWWA, ARRA, NSF 61
- See all Series 710 Male NPT Transition Fittings »
🔧 Common Applications
- Utility Metering Stations
- Industrial Process Monitoring
- Municipal and Industrial Water Systems
- Chemical and Nutrient Transfer Lines
- Geothermal System Connections
| Thread Size (NPT) | DR Rating | Material Options |
|---|---|---|
| 0.75" | DR 7 | 304 SS, 316 SS, C954 Aluminum Bronze, Carbon Steel |
| 1" | DR 7 | 304 SS, 316 SS, C954 Aluminum Bronze, Carbon Steel |
| 1.25" | DR 7 | 304 SS, 316 SS, C954 Aluminum Bronze, Carbon Steel |
| 1.5" | DR 7 | 304 SS, 316 SS, C954 Aluminum Bronze, Carbon Steel |
| 2" | DR 7 | 304 SS, 316 SS, C954 Aluminum Bronze, Carbon Steel |
| 3" | DR 7 | 304 SS, 316 SS, C954 Aluminum Bronze, Carbon Steel |
| 4" | DR 7 | 304 SS, 316 SS, C954 Aluminum Bronze, Carbon Steel |
| 5" | DR 7 | 304 SS, 316 SS, C954 Aluminum Bronze, Carbon Steel |
| 6" | DR 7 | 304 SS, 316 SS, C954 Aluminum Bronze, Carbon Steel |
| 8" | DR 7 | 304 SS, 316 SS, C954 Aluminum Bronze, Carbon Steel |
| 10" | DR 7 | 304 SS, 316 SS, C954 Aluminum Bronze, Carbon Steel |
| 12" | DR 7 | 304 SS, 316 SS, C954 Aluminum Bronze, Carbon Steel |
Note: All 710 Series Male NPT Thread Transition Fittings for DR 7 IPS feature machined barbed ends and precision-machined threads to ensure optimal fusion and leak-free sealing.
These fittings do not meet ASTM D2513 and are not intended for use with natural gas systems.
Be sure to select the correct main size in combination with the appropriate DR 7 IPS rating to meet your specific application requirements.
DR Compatibility Matrix:
| Main Size | DR 7 | DR 9 | DR 11 | DR 17 |
|---|---|---|---|---|
| 0.5" | ✘ | ✘ | ✔ | ✘ |
| 0.75" | ✔ | ✔ | ✔ | ✘ |
| 1" | ✔ | ✔ | ✔ | ✘ |
| 1.25" | ✔ | ✔ | ✔ | ✘ |
| 1.5" | ✔ | ✔ | ✔ | ✘ |
| 2" | ✔ | ✔ | ✔ | ✔ |
| 2.5" | ✘ | ✔ | ✔ | ✘ |
| 3" | ✔ | ✔ | ✔ | ✔ |
| 4" | ✔ | ✔ | ✔ | ✔ |
| 5" | ✔ | ✔ | ✔ | ✔ |
| 6" | ✔ | ✔ | ✔ | ✔ |
| 8" | ✔ | ✔ | ✔ | ✔ |
| 10" | ✔ | ✔ | ✔ | ✔ |
| 12" | ✔ | ✔ | ✔ | ✔ |
