Ultra Blue PVCO IPS Pipe is built for demanding potable water and pressure sewer systems. With a 200 PSI pressure rating and engineered to ASTM F1483, this pipe delivers outstanding strength, efficiency, and durability—all while being easier to handle and install than traditional PVC.
🔍 Why PVCO Is Better Than PVC
PVCO (Molecularly Oriented PVC) is up to 4x stronger and 30–40% lighter than standard PVC due to its advanced manufacturing process. This results in thinner walls, a larger internal diameter, and better hydraulic performance—all without sacrificing durability or compliance.
✅ Key Features & Benefits
- ASTM F1483 Compliant: Designed to meet IPS dimensions and 200 PSI requirements for pressurized systems.
- Stronger Than PVC: 77% higher tensile strength, plus superior resistance to crush, impact, and notch damage.
- Corrosion-Free & Maintenance-Free: Performs in harsh soils with no need for coatings, wrappings, or cathodic protection.
- Efficient Flow Design: Smooth interior with C-Factor of 150 for reduced pumping costs and consistent system performance.
- Lightweight & Easy to Work With: Can be handled manually and cut/beveled on site with basic tools.
📌 Product Specifications
- Product Type: Ultra Blue PVCO Pipe
- Pressure Class: 200 PSI
- Standard: ASTM F1483
- Size Range: 6", 8", 10", 12" IPS
- Length: 20 ft nominal laying length
- End Type: Bell End with Gasketed Joint (ASTM D3139 / F477)
- Material: PVCO, ASTM D1784 Cell Class 12454
- Certifications: ANSI/NSF 61, ANSI/NSF 14*, UL 1285
- Color Options: Blue (potable), Green (sewer), Purple (reclaimed)
💡 Applications
- Potable Water Distribution
- Pressure Sewer and Force Main Systems
- Water Reclamation Infrastructure
- Municipal Pipeline Upgrades
Ultra Blue PVCO IPS Pipe – 200 PSI offers a smarter, lighter, and stronger solution for municipal engineers, contractors, and utility installers. Get the performance of tomorrow’s infrastructure—today.
Made in the USA. Fully compliant with ASTM F1483, ASTM D3139, NSF 61, and related performance standards.
IPS (ASTM F1483)
| PRESSURE CLASS 200 PSI | PIPE STIFFNESS: 48 PSI | ||||||
|---|---|---|---|---|---|---|
| PIPE SIZE (IN) | AVERAGE O.D. (IN) | NOM. I.D. (IN) | MIN. T. (IN) | AVG. E (IN) | APPROX. D° (IN) | APPROX. WGT (LBS/FT) |
| 6 | 6.625 | 6.24 | 0.182 | 4.5 | 8.125 | 2.5 |
| 8 | 8.625 | 8.13 | 0.236 | 4.5 | 10.25 | 4.2 |
| 10 | 10.75 | 10.13 | 0.295 | 5.5 | 12.25 | 6.4 |
| 12 | 12.75 | 12.02 | 0.349 | 5.5 | 14.75 | 8.9 |
