PVC Conduit | DB-100 | California Compliant Power & Telco Duct | 20' Bell End
$2.40
Unit price
/
Select Option
PVC Conduit | DB-100 | California Compliant Power & Telco Duct | 20′ Bell End
Prime Conduit DB-100 PVC Duct is a California-compliant, high-modulus nonmetallic conduit designed for underground electrical and telecom systems. Suitable for direct burial or concrete encasement, this conduit offers exceptional strength, consistent wall thickness, and reliable long-term performance in demanding field conditions.
Each 20′ stick includes a factory-formed bell end for fast, secure solvent-weld joints—eliminating the need for separate couplings. DB-100 conduit meets ASTM F512 and NEMA TC-6 & TC-8 standards and is rated for use with 90°C cable systems.
Key Features & Benefits
- California Compliant DB-100 — Meets 500,000 modulus wall specification for added strength and reliability.
- High-Modulus PVC — Provides increased rigidity and durability for underground and encased installations.
- 20′ Bell-End Sticks — Integral bell end allows quick solvent-weld joints without couplings.
- 90°C Cable Rated — Suitable for high-temperature electrical and telecommunications cable systems.
- Standards Compliant — Manufactured to ASTM F512 and NEMA TC-6/TC-8 specifications.
Product Dimensions & Specifications
| Nom. Size | Part Number | Stick Length | Crate Qty (ft) | Weight per 100 ft (lbs) | Avg. O.D. (in.) | Min. Wall (in.) |
|---|---|---|---|---|---|---|
| 3″ | 68913-020 | 20′ | 2,000 | 95 | 3.500 | 0.112 |
| 4″ | 68915-020 | 20′ | 1,140 | 156 | 4.500 | 0.145 |
| 5″ | 68916-020 | 20′ | 760 | 237 | 5.563 | 0.179 |
| 6″ | 68917-020 | 20′ | 520 | 337 | 6.625 | 0.213 |
Complies with ASTM F512 and NEMA TC-6/TC-8. Suitable for 90°C cable systems and underground electrical or telecom installations.
