Gulfstream 300 Micro Fiber Blower Standard Kit | 48V Power Supply
$15,857.80
Unit price
/
Select Option
Each
Lead Time:
Gulfstream 300 Micro Fiber Blower Standard Kit | 48V Power Supply (US) — Product Overview
The Gulfstream 300 Micro Fiber Blower Standard Kit is designed for installing fiber optic cable into microduct applications. The system supports fiber cable sizes from 2.5 mm to 8 mm and duct sizes from 7 mm to 18 mm.
The Gulfstream 300 kit includes a 48V AC power supply and components required for operation. This kit is supplied with standard accessories and replacement items listed below.
Key Features
- Micro Fiber Installation: Designed for fiber optic cable installation into microduct systems.
- Cable & Duct Compatibility: Supports fiber cable sizes from 2.5 mm to 8 mm and duct sizes from 7 mm to 18 mm.
- Power System: Includes 48V AC power supply for operation.
- Control Features: Includes speed control, forward/reverse switch, emergency stop button, and display monitoring.
Specifications
- Fiber Cable Range: 2.5 mm – 8 mm
- Microduct Range: 7 mm – 18 mm
- Weight: 9 lbs (4.1 kg)
- Power System: 48V AC Power Supply
- Drive: Belt drive
- Maximum Push Force: 30 lbs (133 N)
Included in standard kits:
| Part Number | QTY | Description |
|---|---|---|
| 02290961 | 1 | Plastic Case |
| 02291020 | 1 | Hex Key Set |
| 08784011 | 1 | Large V-Groove Belt, GS300 QC |
| 08783076 | 1 | Seal Kit |
| 08783519 | 1 | O-Ring Kit (qty 5) |
| 08787018 | 1 | Flat Belt, GS300 QC |
| 08787021 | 1 | Rear Insert Guide (3-4mm) |
| 08787022 | 1 | Rear Insert Guide (5-7mm) |
| 08787023 | 1 | Rear Insert Guide (8-10mm) |
| 08787060 | 1 | AC Power Supply, 48V - US |
| 08783508 | 1 | AC Power Supply, 48V - Int'l (must install appropriate plug) |
| 08782212 | 1 | Tripod Plate, 5/8" to 1/4" Adapter |
| 02290383 | 1 | Adjustable HD Tripod, 42" - 65" |
| 08787066 | 1 | Quick Change Tool |
