Series 415 Side Fusion Tapping Saddle | 2" Base | IPS
The Poly-Cam Series 415 Side Fusion Tapping Saddle delivers a robust and low-profile solution for tapping into HDPE pipelines. Engineered with a barbed mechanical design, this tapping saddle is hydraulically compressed into polyethylene or copolymer pipe, forming a durable, high-strength seal. A stainless steel compression ring enhances pullout resistance, while the female-threaded outlet ensures a secure connection for valves or corporation stops.
Designed for compatibility with standard side fusion equipment, the 2" base is field-machinable to match a wide range of main pipe diameters. This results in a custom fit at the jobsite, supporting long-term reliability under pressure and thermal expansion.
With a 335 PSI pressure rating and a 50-year minimum design life at 73.4Ā°F (23Ā°C) and a 2:1 safety factor, this tapping saddle is ideal for utility and industrial HDPE applications.
Key Features & Benefits
- Threaded Branch Outlet: Female NPT or CC (AWWA) threads from 0.5" to 2"
- 2" Pivot Base Design: Field-machinable to match HDPE mains from 2" to 63"
- Mechanical Barbed Seal: Hydraulically compressed for long-lasting performance
- Stainless Compression Ring: Provides superior pullout strength
- Full Pressure Rating: Rated to 335 PSI
- Material Options: C954 Aluminum Bronze (lead-free), 304 SS, 316 SS, and PE 4710 HDPE
- Standards Compliance: ANSI/ASME B1.20.1ā2013 thread specs
- Certified Performance: Meets ASTM D1598, D1599, AWWA C906, NSF 61 (PM13569), ARRA-compliant
- Made in the USA
Common Applications
- Municipal Water Systems
- Industrial Piping Networks
- HDPE Service Taps
- Utility Valve Installations
- Sidewall Fusion for HDPE Systems
Available Configurations (2" BASE IPS)
š View All Series 415 Transition Fittings
| Base Size | Main Size (IN) | Outlet Size & Thread |
|---|---|---|
| 2" BASE | 2" | 0.5" NPT |
| 3" | 0.5" NPT | |
| 4" | 0.5" NPT | |
| 6" | 0.5" NPT | |
| 8" | 0.5" NPT | |
| 10" | 0.5" NPT | |
| 12" | 0.5" NPT | |
| 2" BASE | 2" | 0.75" NPT |
| 3" | 0.75" NPT | |
| 4" | 0.75" NPT | |
| 6" | 0.75" NPT | |
| 8" | 0.75" NPT | |
| 10" | 0.75" NPT | |
| 12" | 0.75" NPT | |
| 2" BASE | 2" | 0.75" CC |
| 3" | 0.75" CC | |
| 4" | 0.75" CC | |
| 6" | 0.75" CC | |
| 8" | 0.75" CC | |
| 10" | 0.75" CC | |
| 12" | 0.75" CC | |
| 2" BASE | 2" | 1" NPT |
| 3" | 1" NPT | |
| 4" | 1" NPT | |
| 6" | 1" NPT | |
| 8" | 1" NPT | |
| 10" | 1" NPT | |
| 12" | 1" NPT | |
| 2" BASE | 2" | 1" CC |
| 3" | 1" CC | |
| 4" | 1" CC | |
| 6" | 1" CC | |
| 8" | 1" CC | |
| 10" | 1" CC | |
| 12" | 1" CC |
