Form 8 Stainless Steel Cover & Gasket Sets | Type 316L | FDA Gasket | IP69 | UL & NSF Certified
$2,004.26
Unit price
/
Select Option
Form 8 Stainless Steel Cover & Gasket Sets | Type 316L | FDA Gasket | IP69 | UL & NSF Certified
Form 8 Stainless Steel Cover & Gasket Sets are engineered for performance, safety, and durability in demanding environments. Ideal for both industrial and sanitary conduit systems, these covers ensure a watertight seal and long-term reliability. Manufactured from Type 316L stainless steel and equipped with an FDA-approved gasket, they meet strict standards for corrosion resistance, hygiene, and compliance.
Key Features & Benefits
- Premium Stainless Steel Construction: Built from Type 316L stainless steel for superior strength, corrosion resistance, and longevity in harsh or sanitary applications.
- Polished “Brite” Finish: Provides a clean, reflective surface that enhances both appearance and resistance to rust, moisture, and chemicals.
- Complete Installation Kit: Includes two Type 316 stainless steel hex head cap screws and nuts for easy assembly and secure attachment to conduit bodies.
- FDA-Approved Neoprene Gasket: Creates a watertight, sanitary seal that meets FDA standards, perfect for food processing and cleanroom environments.
- Exceptional Sealing Protection: The gasket and cover design provide an IP69 rating for protection against dust, high-pressure washdowns, and contaminants.
Certifications & Compliance
- UL / CULUS 514A (File #E307133)
- NSF/ANSI 169 Certified for health and safety standards
- IP69 Rated for dust and high-pressure water resistance
- NEC Compliant for use in electrical conduit systems
- 314 Certified for specific sanitary and electrical use applications
Applications
- Electrical Installations: Ideal for sealing conduit bodies in industrial, commercial, or outdoor electrical systems.
- Food Processing Facilities: Designed for use in environments with strict sanitary requirements.
- Pharmaceutical & Medical Manufacturing: Suitable for sterile and hygienic installations requiring compliance with FDA and NSF standards.
- General Industrial Use: Perfect for factories, processing plants, and chemical environments demanding reliability and corrosion resistance.
Dimensional Data
| Part Number | Trade Size | Length (in) | Width (in) | Height (in) | Bolt Size (in) | Center Hole (in) | Weight (lb/ea) |
|---|---|---|---|---|---|---|---|
| S60500CG00 | 3 | 4.320 | 1.325 | 0.025 | 6-32 | 3.750 | 0.12 |
| S60700CG00 | 1-1/2 | 4.940 | 1.570 | 0.025 | 6-32 | 4.340 | 0.17 |
| S61000CG00 | 1/2 | 5.690 | 1.730 | 0.025 | 6-32 | 5.070 | 0.20 |
| S61200CG00 | 3/4 | 6.600 | 2.150 | 0.025 | 6-32 | 5.800 | 0.30 |
| S61500CG00 | 4 | 7.810 | 2.550 | 0.025 | 6-32 | 7.140 | 0.38 |
| S62000CG00 | 1-1/4 | 10.00 | 3.480 | 0.025 | 6-32 | 9.300 | 0.62 |
| S62500CG00 | 2 | 12.00 | 4.620 | 0.025 | 6-32 | 11.31 | 1.24 |
| S63000CG00 | 2-1/2 | 12.00 | 4.620 | 0.025 | 6-32 | 11.31 | 1.24 |
| S64000CG00 | 1 | 14.63 | 5.830 | 0.025 | 6-32 | 16.05 | 1.91 |
