Union Ball Valve | 8050S Series | Solder x FNPT | Full Port
$30.00
Unit price
/
Select Option
Union Ball Valve | 8050S Series | Solder × FNPT | Full Port | DZR Lead-Free Brass
The Red-White Valve 8050S Union Ball Valve is built for professional-grade performance in high-pressure plumbing and hydronic systems. With a 600 PSI WOG rating, full-port flow design, and DZR (Dezincification-Resistant) lead-free brass construction, it delivers lasting reliability and compliance for potable water, HVAC, and process applications.
Key Features & Benefits
- 600 PSI WOG Rating — Industrial-grade performance for demanding hydronic, plumbing, and process applications.
- DZR Lead-Free Brass Body — Corrosion-resistant and certified for potable water under AB1953 and NSF/ANSI/CAN 61 & 372.
- Solder × FNPT Connection — Combines a permanent solder seal with threaded flexibility for easy integration.
- Full-Port Chrome-Plated Ball — Provides unrestricted flow and smooth operation with minimal pressure loss.
- Union Body Design — Enables maintenance and replacement without cutting pipe.
- Virgin PTFE Seats — Ensures a tight seal and superior chemical resistance.
- Adjustable Packing Gland — Maintains long-term leak-free performance.
- Blow-Out Proof Stem — Safety-engineered for high-pressure environments.
Technical Specifications
- Body Material: DZR Lead-Free Brass (ASTM B927 C27453)
- Seats: Virgin PTFE (TF1502)
- O-Rings: EPDM Perox 70 SH (NSF Approved)
- Pressure Rating: 600 PSI WOG
-
Temperature Range: 15°F to 260°F (–9°C to 127°C)
- Below 32°F – use antifreeze additives
- Above 212°F – use anti-boil additives
- Certifications: AB1953, NSF/ANSI/CAN 61 & 372
Dimensions & Weight
| Part # | Size | φT [in] | φA [in] | B [in] | D [in] | E [in] | F [in] | G [in] | H [in] | L [in] | φP [in] | Wt. [lb] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8050S 075S075S | 3/4″ | 3/4 – 14 NPT | 0.877–0.880 | 0.75 | 0.73 | 2.57 | 3.38 | 5.55 | 2.20 | 3.60 | 0.73 | 0.93 |
| 8050S 100S100S | 1″ | 1 – 11.5 NPT | 1.128–1.131 | 0.91 | 0.75 | 3.00 | 4.00 | 7.23 | 2.57 | 4.98 | 0.98 | 1.49 |
| 8050S 125S125S | 1-1/4″ | 1-1/4 – 11.5 NPT | 1.377–1.381 | 0.98 | 0.77 | 3.30 | 4.28 | 7.35 | 2.74 | 4.98 | 1.23 | 2.09 |
Material
| Component | Material | Specification |
|---|---|---|
| Body & Union | DZR Lead-Free Brass | ASTM B927 C27453 |
| Ball | Lead-Free Brass / Chrome Plated | ASTM B927 C27450 |
| Seats | Virgin PTFE | TF1502 |
| O-Rings | EPDM Perox 70 SH | NSF Approved |
| Handle | Steel / Dacromet® Plated | ASTM A36 |
Warning (California Prop 65): This product can expose you to chemicals including lead, known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, visit www.P65Warnings.ca.gov.
