Split Sleeve Sweeps | Elbows

Split Sleeve Sweeps | Elbows — Product Overview

Split Sleeve Sweeps | Schedule 40 PVC Elbows | Prime Conduit | Multiple Angles & Radii | Electrical & Telecom Conduit Repairs

Split Sleeve Sweeps provide a versatile solution for directional changes in Schedule 40 conduit systems. Available in precise angles—90°, 45°, 30°, 22½°, and 11¼°—these elbows simplify repairs and retrofits by allowing bends to be added without removing existing cables.

Each sweep comes in multiple radii (24", 36", 48", and 60") to fit a wide range of conduit layouts. For added flexibility, two 45° sweeps can be combined to form a 90° bend. Manufactured from rugged Schedule 40 PVC, these split sleeves maintain full structural integrity while reducing installation time and labor.

Key Features:

• Multiple angle options: 90°, 45°, 30°, 22½°, and 11¼° for precise directional changes
• Radius choices: 24", 36", 48", and 60" sweeps to match conduit runs
• Flexible installation: Two 45° sweeps can combine into a 90° bend
• Durable PVC construction: Schedule 40 rated, impact- and corrosion-resistant
• Common trade sizes: Available in 2", 3", 4", and 6"
• Clear part coding: Easy-to-identify designations for fast ordering

Split Sleeve Sweeps make conduit bending and repairs faster, easier, and code-compliant—ideal for electrical and telecom contractors.

Technical Document:

• Split Duct and Kits Catalog

Split Sleeve Sweeps | Specifications
