Split Duct | Sch 40 and 80 Split PVC Conduit | 10 ft Sticks
Split Duct — 10-foot sticks of two-piece split PVC conduit with a tongue-and-groove joint, for repairing damaged conduit around installed cable without cutting or splicing the conductors.
Prime Split Duct is a full 10-foot length of PVC conduit split lengthwise into two halves (the photo shows short sections for illustration). The halves snap together over the cable with an interlocking tongue-and-groove joint, and the joints are taped and strapped to make a rigid run. Sections can be staggered and butted together for any length of repair. Available in Schedule 40, Schedule 80 and 4" Type C telephone duct, 2" through 6".
Key Features
- 10-foot sticks: full-length conduit, priced per foot and sold by the bundle
- No cable removal: repairs go on around existing conductors
- Tongue-and-groove joint: halves interlock and hold the conduit's original dimensions
- Extra-rugged PVC: a compound made for power and telecom duct, high impact strength, UV resistant
- Complete system: split duct couplers and split sleeve sweeps join the duct to itself and to existing conduit
- Sold by the bundle: full bundles only; bundle footage per size is in the table and pre-filled in the quantity box
- Quoted per order: made to order, manufacturing lead time applies. Call (815) 337-8845 or use the quote button with the size and footage you need
- Installation guide: Prime's stagger, tape and strap procedure is in the spec sheet under Documents
Before You Order
These are Prime's own application notes and they matter on a utility job:
- Split duct butts up to the existing conduit; it does not slide over it. The split couplers go over the outside of the joint between split duct and conduit.
- Not a listed product. There is no ETL or UL standard for split duct. It is a utility and telecom repair product; where the NEC governs, split duct is not accepted as a permanent repair without the inspector's approval, so confirm with the authority having jurisdiction before you order.
- Outdoor and underground use. Not intended for indoor use or to penetrate firewalls. Prime does not recommend concrete encasement over split duct.
- Made from UL 651 Schedule 40 conduit, rated for 90°C conductors and a 50°C ambient.
- Order to the conduit size: 2" split duct and 2" split couplers for a 2" conduit repair.
Order Guide
| Part Number | Size | Wall | Length | O.D. | Bundle (ft, min. order) | Bundle Wt (lb) |
|---|---|---|---|---|---|---|
| 49011SD-010 | 2" | Sch 40 | 10 ft | 2.375 | 700 | 561 |
| 49411SD-010 | 2" | Sch 80 | 10 ft | 2.375 | 700 | 702 |
| 49012SD-010 | 2-1/2" | Sch 40 | 10 ft | 2.875 | 460 | 562 |
| 49013SD-010 | 3" | Sch 40 | 10 ft | 3.500 | 500 | 830 |
| 49014SD-010 | 3-1/2" | Sch 40 | 10 ft | 4.000 | 290 | 560 |
| 49015SD-010 | 4" | Sch 40 | 10 ft | 4.500 | 290 | 680 |
| 49415SD-010 | 4" | Sch 80 | 10 ft | 4.500 | 290 | 890 |
| 68515SD-010 | 4" | Type C | 10 ft | 4.350 | 320 | 624 |
| 49016SD-010 | 5" | Sch 40 | 10 ft | 5.563 | 230 | 718 |
| 49416SD-010 | 5" | Sch 80 | 10 ft | 5.563 | 380 | 1,625 |
| 49017SD-010 | 6" | Sch 40 | 10 ft | 6.625 | 130 | 523 |
10-foot sticks, priced per foot, sold in full bundles. The bundle footage is the minimum order and the order increment for each size. Ships by freight from the manufacturer. Blue rows are Schedule 80; the tan row is Type C telephone duct.
Complete the Repair
- Split duct couplers to join split duct to itself and to existing conduit. View Split Duct Couplers Here > LINK
- Split sleeve couplings, no center stop, for joining split duct to existing duct. View Split Sleeve Couplings Here > LINK
- Split kits for a short repair without a full bundle: a 2-foot split section with two split couplings. View Sch 40 Split Kits Here > LINK
