1" CSA Gas Ball Valve | 5150F Series | Brass Body | 125 PSI
$12.25
Unit price
/
Select Option
1″ CSA Gas Ball Valve | 5150F Series | Brass Body | 125 PSI
Red-White Valve’s 5150F CSA Gas Ball Valve offers reliable performance and long-term durability for natural gas, propane, and compressed air systems. This 1-piece brass valve features FNPT threaded ends (ASME B1.20.1-NPT) and a chrome-plated brass ball for smooth operation and corrosion resistance. Designed for 125 PSI (400 CWP) service, it meets ANSI Z21.15 / CSA 9.1 standards, making it ideal for residential, commercial, and light industrial gas installations.
Key Features & Benefits
- 125 PSI (400 CWP) Rating — Certified for gas service, ideal for high-pressure propane and natural gas systems.
- Heavy-Duty Brass Body — Machined from UNS C37700 brass for strength, corrosion resistance, and long lifespan.
- FNPT × FNPT Connections — ASME B1.20.1-NPT threaded ends ensure secure, vibration-resistant seals.
- Chrome-Plated Brass Ball — Provides low-friction operation and extended wear resistance.
- PTFE Seats & NBR O-Rings — Leak-free sealing under fluctuating temperature and pressure conditions.
- CSA & ASME Compliance — Meets ANSI Z21.15 / CSA 9.1, ASME B16.44, and CSA 9.4 standards for safe, code-compliant performance.
- Aluminum Handle — Rugged, lightweight ANSI A380 aluminum lever with plated steel screw.
Technical Specifications
| Parameter | Details |
|---|---|
| Pressure Rating | 125 PSI (400 CWP) |
| Connections | FNPT × FNPT (ASME B1.20.1-NPT) |
| Body Material | Brass UNS C37700 |
| Ball Material | Brass / Chrome Plated |
| Seat Material | PTFE (Commercial Grade) |
| O-Rings | NBR (Commercial Grade) |
| Handle | Aluminum ANSI A380 |
| Certifications | ANSI Z21.15 / CSA 9.1 | ASME B16.44 | CSA 9.4 |
Dimensions / Weight
| Size | T | W [in] | H [in] | L [in] | DN [in] | C [in] | Wt. [lb] |
|---|---|---|---|---|---|---|---|
| ⅜″ | ⅜–14 NPT | 2.03 | 1.42 | 1.38 | 0.39 | 0.47 | 0.26 |
| ½″ | ½–14 NPT | 2.36 | 1.42 | 1.38 | 0.39 | 0.61 | 0.34 |
| ¾″ | ¾–14 NPT | 2.60 | 1.54 | 1.48 | 0.59 | 0.63 | 0.60 |
| 1″ | 1–14 NPT | 3.11 | 1.78 | 1.81 | 0.75 | 0.75 | 1.01 |
Material Construction
| # | Part | Material | Specification |
|---|---|---|---|
| 1 | Body | Brass | UNS C37700 |
| 2 | Seat | PTFE | Commercial Grade |
| 3 | Ball | Brass / Chrome Plated | UNS C37700 |
| 4 | Cap | Brass | UNS C37700 |
| 5 | Screw | Plated Steel | ASME SA6 |
| 6 | Stem | Brass | UNS C37700 |
| 7 | O-Ring | NBR | Commercial Grade |
| 8 | Handle | Aluminum | ANSI A380 |
| 9 | Packing | PTFE | Commercial Grade |
| 10 | O-Ring | NBR | Commercial Grade |
Warning (California Prop 65): This product can expose you to chemicals including lead, known to the State of California to cause cancer and reproductive harm. For more information, visit www.P65Warnings.ca.gov.
