415 Series Side Fusion Tapping Saddle | 1.5" Base | IPS

Poly-Cam’s Series 415 Side Fusion Tapping Saddle provides a rugged, low-profile solution for creating secure branch outlets on HDPE mains. This mechanically barbed tapping saddle is hydraulically compressed into polyethylene or pipe-grade copolymer material, forming a durable connection that performs reliably in demanding utility environments.

A stainless steel compression ring enhances pullout strength, while the female-threaded outlet enables secure installation of corporation stops or valves. Designed for use with standard side fusion equipment, this fitting can be field-machined to match the main pipe’s radius, allowing for a precise fusion process at the jobsite.

The fitting delivers a permanent, pressure-rated solution with a minimum 50-year design life at 73.4°F (23°C) and a 2:1 safety factor. Ideal for both municipal and industrial applications, the 1.5" base supports IPS mains ranging from 2" to 63" in diameter.

Key Features & Benefits

• Threaded Branch Outlet: Female NPT or CC thread options from 0.5" to 2"
• Side Fusion Compatibility: Installs using standard sidewall fusion equipment
• Heavy-Duty Mechanical Seal: Stainless steel compression ring maximizes pullout resistance
• Custom Fit Radius: Machinable base accommodates 2"–63" main pipe diameters
• High Pressure Rating: Rated to 335 PSI with full fusion performance
• Material Options: C954 Aluminum Bronze (lead-free), 304 SS, 316 SS, and PE 4710 HDPE
• NSF & ASTM Certified: Meets NSF 61, ASTM D1598, D1599, ASTM F2620, AWWA C906, ARRA requirements
• Thread Compliance: All NPT threads manufactured to ANSI/ASME B1.20.1 – 2013

Common Applications

• Municipal Water Distribution
• HDPE Service Taps
• Industrial Fluid Systems
• Sidewall Fusion Projects
• Utility Valve Integration

Available Configurations (1.5" BASE IPS)
