Heavy-Duty Expansion Anchors — Product Overview

Heavy-Duty Expansion Anchors are designed for fastening applications in concrete. Each anchor is installed in a pre-drilled hole, where the plug expands as the anchor is driven into it to create a solid hold in the concrete.

Choose from three UNC thread sizes: 3/4"-10 UNC, 5/8"-11 UNC, and 1/2"-13 UNC. Each size has manufacturer-published allowable working loads for tension and shear, as shown in the Ordering Information table below.

Important: Confirm the required thread size and allowable working load before ordering. Condux specifies the published load ratings for 4,000 psi concrete, with allowable shear loads based on SAE Grade 5 capscrews.

Key Features

• Concrete Fastening: Designed for installation in pre-drilled holes in concrete.
• Expansion Mechanism: The plug expands as the anchor is driven into it, producing a solid hold.
• Three Thread Sizes: Available in 3/4"-10 UNC, 5/8"-11 UNC, and 1/2"-13 UNC configurations.
• Published Tension Ratings: Manufacturer-listed allowable tension loads vary by anchor size.
• Published Shear Ratings: Allowable shear loads are provided for use with SAE Grade 5 capscrews.

Thread Size Selection

Each manufacturer part number corresponds to a specific UNC thread designation. Select the thread size required by your application and confirm the load rating for that configuration.

• MPN 08409900: 3/4"-10 UNC threads.
• MPN 08409901: 5/8"-11 UNC threads.
• MPN 08409902: 1/2"-13 UNC threads.

Ordering Information

The following allowable working loads are published by Condux for each expansion anchor size.

Load Rating Note: Allowable working loads are based on 4,000 psi concrete. Allowable shear loads are based on the use of SAE Grade 5 capscrews.

Select the appropriate thread size and review the manufacturer's published load ratings before installation. For product questions, contact Utility Pipe Supply at (815) 337-8845.
