Quadrant Block Support Bar — Product Overview

The Quadrant Block Support Bar is a steel bar designed to support quadrant blocks or cable guides at street level during cable-pulling operations.

Condux lists this support bar under manufacturer part number 08091440, with a diameter of 1.25" (32 mm) and a length of 4' (1.2 m).

Product Features

• Steel Construction: Manufacturer-specified steel support bar.
• 1.25" Diameter: Published bar diameter of 1.25" (32 mm).
• 4' Length: Published overall bar length of 4' (1.2 m).
• Street-Level Support: Designed to support quadrant blocks or cable guides at street level.
• Condux Part Number: Manufacturer part number 08091440 for accurate identification and ordering.

Related Condux Cable Guides

The following are related Condux quadrant block and cable guide product families. Confirm the specific equipment configuration before use.

• Heavy-Duty Quadrant Block, 90°: Part numbers 08539100, 08539200, 08539650, and 08539710. LINK
• 60° Quad Block: Part number 08539220. LINK
• Three Sheave Cable Guide: Part numbers 08539600 and 08539800. LINK
• Fiber Optic Quadrant Block: Part number 08539350. LINK

Applications

• Quadrant Block Support: Supports quadrant blocks at street level.
• Cable Guide Support: Provides a support-bar component for appropriate cable guide setups.
• Cable-Pulling Equipment: Intended for use as part of Condux cable-guidance arrangements.

Ordering Information

The following dimensions are published by Condux for the Support Bar.

Ordering Note: Confirm the support bar dimensions and the requirements of the intended quadrant block or cable guide before ordering.
